Features

  • 流量测量（典型读数的2%）
  • 自动通道切换和基线校准
  • 50至2000标准升每分钟（SLPM）

DESCRIPTION

对于人体代谢舱，我们提供Promethion FG系列流量发生仪。FG-250的范围为50-250 SLPM，FG-2000的范围为250-2000 SLPM。Promethion
系统能够以每秒一次的采样率进行连续的代谢测量。

View map of Promethion Core and Promethion Room Calorimetry academic installations

specs

Main Flow
Range
  • FG-250:
 50-250 SLPM
  • FG-2000:
 250-2000 SLPM
Accuracy
  • FG-250:
 2% of reading typical over range of 50-250 SLPM
  • FG-2000:
 2% of reading typical over range of 250-1000 SLPM
  • Resolution:
 .01 L/min
  • Sensor type:
 Differential Pressure
Sample Flow
  • Range:
 0-2000 ml/min
  • Accuracy:
 2% of reading typical over range of 0-2000 ml/min
  • Resolution:
 0.001 ml/min
  • Sensor type:
 Differential Pressure
Digital Interface:
  • Sable Bus:
 CAN Protocol, direct digital data transfer
Display: Digital 4 x 16 alphanumeric LCD
Recommended Calibration Interval: 1 Year
Power Requirements: 12 – 24 VDC (data); universal adapter supplied
12VDC, 10A (high power); universal adapter supplied
Dimensions (W x D x H): 19 x 21 x 7 in. (48.3 x 53.3 x 17.8 cm)
Weight: 20lbs (9.1 kg)
